Worknc 2022 System Requirements is an important issue that you should consider if you aim to get maximum efficiency from your computer.

System Requirements for WORKNC 2022

Processor: Quad Core Intel® Xeon® E5 (4 Cores) Or Intel® Core™ i7 (4 Cores) (Multicore allows to exploit the possibilities of WORKNC)
Operating system: Windows® 10 Pro 64 Bits (*), Windows Server 2012 R2 – (Windows 8/8.1, Windows 7 and Windows Server 2008 R2, are not supported by WORKNC)
Graphics card: Minimum Ram 2 GB, Open/GL 3.3 minimum compatibility(**), Processor Nvidia Quadro recommended
Hard disk: System disk: 500 GB Disk space SSD | Data disk: Optional according to the needs of storage (Hard Disk SATA)
Screen: 22″ Monitor minimum resolution, 1920×1080
Ram: 8-12 GB DDR4 2600Mhz ECC
Dongle connection: 1 USB port
Mouse: Optical Mouse wheel with 2 buttons

Processor: Intel Xeon Bronze (12 to 24 Cores) or Intel Core i9-67XX (8 Cores) (Multicore allows to exploit the possibilities of WORKNC)
Operating system: Windows® 10 Pro 64 Bits (*),Windows Server 2012 R2 – (Windows 8/8.1, Windows 7 and Windows Server 2008 R2, are not supported by WORKNC)
Graphics card: Ram : 4-8 Gb, Open/GL 3.3 minimum compatibility (**), Processor Nvidia Quadro recommended
Hard disk: System Disk : 500 GB SSD M.2 PCIe NVMe Classe 40 or 50| Data disk: 1 TB Disk space SSD SATA ou M.2 PCIe NVMe
Screen: 24″ to 30″ Monitor – Resolution 1920×1080 – 1 or 2 screens
Ram: 32 GB DDR4 2933 MHz ECC
Dongle connection: 1 USB port
Mouse: Optical Mouse wheel with 2 buttons

(*) The following Windows parameters should not be used : transition effect for menus and tooltips, and pointer shadow.

(**) Depends on the size of the part (Large parts will have higher memory requirements)

We recommend you always download the latest graphic card driver from the supplier’s Web site.
